Erich Jaeger alternative

711248

Adapter coil - with 7P/12V plug (ISO 1724) and 7P/12V plug (SAE J560)

Use this article number as the starting point for a quote: ConnectorRoute checks suitable alternatives, fit, availability, MOQ and lead time before proposing a replacement route.

Request quote Official Erich Jaeger product page

ConnectorRoute is independent and is not affiliated with Erich Jaeger GmbH. Brand and article references are used for identification and cross-reference purposes only.

System products

Products often checked together with this reference: matching plugs, sockets, coil cables, adapters and supply cables. Generic installation material is intentionally excluded.

Product context

Product description and application

Erich Jaeger 711248 is Adapter coil - with 7P/12V plug (ISO 1724) and 7P/12V plug (SAE J560). This adapter connects two connector standards or layouts. It is especially important to verify the pin allocation, because the mechanical fit alone does not prove that every lighting and auxiliary function is routed correctly. ISO 1724 - Type N, SAE J560 and 12V should be verified against the vehicle or trailer wiring diagram. The known selection frame is ISO 1724 - Type N, SAE J560, 12V, 7P and commercial vehicles, cars, agriculture.

What does 711248 do?

This page treats 711248 as a real vehicle-electrical component, not just as a search term. In practice the part is selected by connector family, electrical standard, voltage, pole count and the way it is mounted or connected in the vehicle. For a adapter, the mating component and cable route are part of the decision.

Technical checks before replacing it

Check the product drawing, connector layout, mounting position, electrical load and mating component before treating another part as equivalent.

How ConnectorRoute approaches the alternative

ConnectorRoute starts with the Erich Jaeger number, then checks the application: vehicle type, yearly volume, existing mating connector, drawings or photos, required approval level and supply continuity. Only after that does an alternative become a quoteable route instead of a guess.

Products that belong in the same request

For a useful quote, include related system parts where possible: 101100 7P/12V Socket (ISO 1724 - Type N), 201212 7P/12V Plug (ISO 1724 - Type N), 611263 7P/12V «ExperTech™» Straight Cable (SAE J560 Primary), 601040 7P/12V Coil (ISO 1724 - Type N), 101285 7P/12V Socket (ISO 1724 - Type N). That helps prevent solving one article number while leaving the matching plug, socket, coil cable, adapter or supply cable as the next bottleneck.

Structured product facts

Article number
711248
Product family
adapter
Category
adapter
Standard
ISO 1724 - Type N, SAE J560
Voltage
12V
Poles
7P
Industry
commercial vehicles, cars, agriculture
Related product families
component
Working length [in m]
3
Max. working length [in m]
4
Max. extension length [in m]
4.6
Wire cross-sectional area
6x 1.5mm² + 1x 2.5mm²
Packaging
PE bag

711248

Questions about this reference

Can Erich Jaeger 711248 be replaced one-to-one?

Sometimes, but it should not be assumed from the article number alone. The connector standard, pole count, voltage, contact type, seal, cable entry and application need to match before ConnectorRoute confirms a replacement.

What should I send with an enquiry?

Send the Erich Jaeger article number, quantities, yearly demand, photos of the installed part, drawings if available, the mating connector and any vehicle or trailer information.

Why does the page mention related products?

Truck and trailer electrics are system-based. A socket, plug, coil cable, adapter and supply cable often need to be checked together to avoid a partial replacement route.

Technical specifications

Technical data

Working length [in m]
3
Max. working length [in m]
4
Max. extension length [in m]
4.6
Wire cross-sectional area
6x 1.5mm² + 1x 2.5mm²
Packaging
PE bag
