Erich Jaeger alternative
601069
7P/12V Coil (ISO 1724 - Type N)
Use this article number as the starting point for a quote: ConnectorRoute checks suitable alternatives, fit, availability, MOQ and lead time before proposing a replacement route.
ConnectorRoute is independent and is not affiliated with Erich Jaeger GmbH. Brand and article references are used for identification and cross-reference purposes only.
System products
Related products in the same connection route
Products often checked together with this reference: matching plugs, sockets, coil cables, adapters and supply cables. Generic installation material is intentionally excluded.
Product context
Product description and application
Erich Jaeger 601069 is 7P/12V Coil (ISO 1724 - Type N). This coil cable forms the flexible link between towing vehicle and trailer. Working length, maximum extension length, cable material and conductor cross-section matter just as much as the connector standard. ISO 1724 - Type N and 12V should be verified against the vehicle or trailer wiring diagram. The known selection frame is ISO 1724 - Type N, 12V, 7P and agriculture, cars.
What does 601069 do?
This page treats 601069 as a real vehicle-electrical component, not just as a search term. In practice the part is selected by connector family, electrical standard, voltage, pole count and the way it is mounted or connected in the vehicle. For a coil cable, the mating component and cable route are part of the decision.
Technical checks before replacing it
The public product data highlights: Contact surface: standard (CuZn), Protection: IP 44, Cable outlet: PG gland, Type of seal: sealing plug, Max. working length [in m]: 3,00, Max. extension length [in m]: 4,50 and Wire cross-sectional area: 6x 1.5mm² + 1x 2.5mm². These details matter because a replacement can have the right article description while still failing on cable entry, contact termination, sealing, housing material or installation space.
How ConnectorRoute approaches the alternative
ConnectorRoute starts with the Erich Jaeger number, then checks the application: vehicle type, yearly volume, existing mating connector, drawings or photos, required approval level and supply continuity. Only after that does an alternative become a quoteable route instead of a guess.
Products that belong in the same request
For a useful quote, include related system parts where possible: 101100 7P/12V Socket (ISO 1724 - Type N), 201212 7P/12V Plug (ISO 1724 - Type N), 311164 Economy "Shorty" mini short adapter - from vehicle (13P/12V) to trailer (7P/12V), 101285 7P/12V Socket (ISO 1724 - Type N), 201005 7P/12V Plug (ISO 1724 - Type N). That helps prevent solving one article number while leaving the matching plug, socket, coil cable, adapter or supply cable as the next bottleneck.
Structured product facts
- Article number
- 601069
- Product family
- coil cable
- Category
- coil cable
- Standard
- ISO 1724 - Type N
- Voltage
- 12V
- Poles
- 7P
- Industry
- agriculture, cars
- Related product families
- component
- Working length [in m]
- 3
- Max. working length [in m]
- 4
- Max. extension length [in m]
- 4.6
- Wire cross-sectional area
- 6x 1.5mm² + 1x 2.5mm²
- Protection
- IP 44
Questions about this reference
Can Erich Jaeger 601069 be replaced one-to-one?
Sometimes, but it should not be assumed from the article number alone. The connector standard, pole count, voltage, contact type, seal, cable entry and application need to match before ConnectorRoute confirms a replacement.
What should I send with an enquiry?
Send the Erich Jaeger article number, quantities, yearly demand, photos of the installed part, drawings if available, the mating connector and any vehicle or trailer information.
Why does the page mention related products?
Truck and trailer electrics are system-based. A socket, plug, coil cable, adapter and supply cable often need to be checked together to avoid a partial replacement route.
Technical specifications
Technical data
- Working length [in m]
- 3
- Max. working length [in m]
- 4
- Max. extension length [in m]
- 4.6
- Wire cross-sectional area
- 6x 1.5mm² + 1x 2.5mm²
- Protection
- IP 44
- Product group
- coil cable
- Standard
- ISO 1724 - Type N
- Industry
- agriculture, cars
- Temperature resistance [in °C]
- -40.0 - 100.0
- Voltage [in V]
- 12
- Packaging
- retail bag
- Branding
- ERICH JAEGER
- Special feature
- L1 = 1250mm | L2 = 250mm
- Type of seal
- sealing plug
- Cable color
- black
- Contact surface
- standard (CuZn)
- Housing color
- silver-colored
- Housing material
- break-proof metal
- Material of cable
- PUR
- Cable outlet
- PG gland
- Mounting of cable and socket/plug
- screwed
- No. of connected plugs
- 2
- No. of connected sockets
- 0
- No. of poles
- 07
- Protection
- IP 44
- Max. extension length [in feet]
- 15,00
- Max. extension length [in m]
- 4,50
- Max. working length [in m]
- 3,00
- No. of coils
- 43
- Outer coil diameter [in mm]
- 50,00
- Wire cross-sectional area
- 6x 1.5mm² + 1x 2.5mm²
- cable cross-sectional area [in mm]
- 9,50
